10A 250V 3kW Mode 2 EV Charger SAE J772 With AU/NZ 10A Plug
- Brand: OEM
- Product Code: ANS-T1-3.6kW
- Availability: In Stock
-
$160
Product Information
Product Listing:
Introducing the 10A 3kW Mode 2 EV Charger, your ultimate solution for convenient and efficient electric vehicle charging at home or on the go. As a leading manufacturer of EV charging accessories, we understand the importance of reliable and accessible charging for every EV owner. This innovative charger delivers a perfect blend of power, portability, and safety, making it an ideal choice for a wide range of applications.
Key Features:
Powerful 3kW charging: Charges your EV quickly and efficiently, adding up to 25km of range per hour.
Universal compatibility: Works seamlessly with all EVs equipped with a Type 2 charging port, including Tesla with an adapter.
Portable design: Lightweight and compact, easily fits in your trunk for convenient charging anywhere.
Durable construction: Built with high-quality materials for long-lasting performance and reliability.
Multiple safety features: Includes overcurrent, overvoltage, and short circuit protection for worry-free charging.
AU/NZ compliant: Meets all safety and regulatory standards for Australia and New Zealand.
Applications:
Home charging: Conveniently charge your EV overnight or during the day with the included AU/NZ plug.
Workplace charging: Provide employees with a convenient charging option at your workplace.
Public charging: Ideal for hotels, restaurants, and other businesses to offer EV charging services.
Emergency charging: Keep a portable charger in your car for unexpected situations.
Innovation and Value:
This 10A 3kW Mode 2 EV Charger represents the cutting edge of EV charging technology. Its innovative design combines portability, power, and safety, making it an invaluable asset for any EV owner. With its affordable price and versatile features, this charger offers exceptional value for money.
Choose the 10A 3kW Mode 2 EV Charger for a reliable and convenient charging experience that keeps you moving.
Page Description:
Looking for a powerful and portable EV charger for home or on-the-go? Look no further than the 10A 3kW Mode 2 EV Charger. This innovative charger delivers fast charging, universal compatibility, and multiple safety features, making it the perfect choice for any EV owner. Order yours today and experience the convenience of reliable EV charging.
250V 3kW Mode 2 EV Charger
,SAE J772 Mode 2 EV Charger
,10A 3kW Mode 2 EV Charger
Product Name: |
Portable EV Charger |
Amps: |
16A |
Voltage: |
250V |
Power: |
3.6kW |
Amps Switch: |
6-16A |
Protection: |
Over Current，over Voltage .etc |
Logo: |
Support Customzation |
Wall Side Plug: |
AU/NZ Plug |
Product Name: |
Portable EV Charger |
Amps: |
16A |
Voltage: |
250V |
Power: |
3.6kW |
Amps Switch: |
6-16A |
Protection: |
Over Current，over Voltage .etc |
Logo: |
Support Customzation |
Wall Side Plug: |
AU/NZ Plug |
SAE J772 EV Chargers 10A 250V 3.6kW with AU/NZ 10A Plug Portable EV Charger
PRODUCT DESCRIPTION
Portable EV Charger is much convenient, portable, plug-and-play. This product is independently researched and accordance with the latest international standards. They apply to more than 95% standard EV cars. It has good performance when charging. There are more electrical protections and direct human-computer interaction interface. Control box is durable by adopting ergonomic surface design which makes the shell become solider and stronger. It is also small and exquisite.
| Item | Mode 2 EV Charger portable charger |
| Install | Portable, plug and Play |
| Output Current | 6A,10A Max. |
| Rated power | 3kW Max |
| Input Voltage AC | 110-250V 50Hz/60Hz |
| International Protection Marking | IP66 |
| Output Detection |
1.Short circuit protection 2.Over and under frequency protection 3. Over and under Current Protection 4.Leakage Current Protection (restart recover) 5.Over Temperature Protection 6.Overload protection (self-checking recover) 7. Ground Protection 8.Over voltage and under-voltage protection 9.Lighting Protection |
| Operating Temperature | -25℃~+55℃ |
| Storage Temperature | -40℃~+80℃ |
| Operating Humidity | 20%-85% |
| Dimension |
Control Box:200mm(L) X 93mm(W)X51.5mm(H) Regular length: 5Meter or Customized (L) |
| Weight | 2.8kg |
| Standard | IEC 62752 , IEC 61851 |
| Carton Measure | 340*300*110MM |
|
Condition |
LED Display Status | |||
| Green (One) | Green (Two) | Green (Three) | Fault (Red) | |
| Initial Mode | Light on | Lights Off | Lights Off | Lights Off |
| Connected mode | Light on | Twinkle (1S) | Lights Off | Lights Off |
| Charging Mode | Racing light | Racing light | Racing light | Lights Off |
| Finished Mode | Light On | Lights On | Lights On | Lights Off |
| Fault Mode | Light Off | Lights Off | Lights Off | Twinkle |
How to start charging
Step 1. Take out the charger and firmly insert the plug into socket-outlet.
Step 2. Pull cap lightly, completely plug the vehicle connector into your vehicle inlet.
Step 3. Factory default current is 32A, please press the button of "CURRENT SETTING" to adjust your required current. amperes to max. 32 ampere cycles. The device will default to the last current setting when you charge next time.
Step 4. The device start charging automatically while the READY/CHARGE, POWER indicators are all green.
How to stop charging
Step 1. Disconnect the vehicle connector from the vehicle inlet.
Step 2. Close protective cap of vehicle inlet, put on the protective cap of vehicle connector.
Step 3. Disconnect the plug from the socket-outlet.
Step 4. Pack up the EV charger cable and put into the bag.
Caution:
a. Please check if the device is intact and items are accordance with the packing list when you receive the package. If there are any abnormalities, please contact the sales timely or reject the goods.
b. Power-supply side input cable should be at least 3x6mm ² It is suggested that the power distribution is done by the professionals.
c. Do not submerge the control box or charging connector in water, and don't step on, pull, fold or knot the cable.
d. Ensure charging connector, plug, cable and control box are free of any abnormalities such as scratches, rusts, cracks, etc.
e. Don't charge if the socket is damaged, rusted, cracked or loosely connected, then contact the professionals to dispose.
f. Wipe with a clean and dry cloth if the plug gets dirty or wet.
g. Ensure power plug and socket are consistent before charging, especially the Current & Voltage.
h. Please check the input current and make sure to reduce charging current to below the input current.
i. Do not place the charging cable near high temperature object when it is working
Certification: CE
